Solar panels are often linked with hot, sunny weather. However, there is an important fact that many people do not know. Solar panels are usually most efficient when the solar cells are cool, not extremely hot. In fact, the standard test temperature for solar panels is 25°C at the cell level. This does not mean that 25°C is a perfect outdoor air temperature. Instead, it is a reference point used to compare solar panel performance.
Therefore, when choosing solar panels for a home or business, temperature should be considered along with sunlight, panel quality, installation, shading and ventilation. For businesses, these factors are especially important because a large solar system can produce electricity for many years.
What Temperature Are Solar Panels Most Efficient At?
In simple terms, solar panels perform best when their cell temperature is around 25°C. This is the reference temperature used under Standard Test Conditions, or STC. Under STC, manufacturers test panels with 1,000 W/m² of sunlight and a cell temperature of 25°C.
However, the temperature of the solar cell is not the same as the outside air temperature.
For example, an outdoor temperature of 25°C can cause a solar panel to become much hotter when it receives strong sunlight. A panel may reach a cell temperature of 40°C, 50°C or even higher. As a result, the panel can produce less power than its laboratory rating.
So, a sunny 25°C day does not always mean the panel is operating at 25°C.
Why Do Solar Panels Become Less Efficient When Hot?
Solar panels use photovoltaic cells to turn sunlight into electricity. When sunlight reaches the cells, some of that energy becomes electricity. However, some energy also becomes heat.
As the cell temperature rises, the electrical voltage produced by the solar cell usually falls. There can be a small increase in current, but the drop in voltage is more important. Consequently, the panel’s overall power output decreases. The U.S. Department of Energy also explains that solar cells generally work better at lower temperatures because higher temperatures reduce voltage.
This effect is measured using a power temperature coefficient.
For example, many crystalline silicon panels have a temperature coefficient around -0.3% to -0.5% per °C. The exact value depends on the panel model and technology. Research covering commercial crystalline silicon modules has reported an average drop of about 0.45% in efficiency for each 1°C rise in temperature.
A Simple Solar Panel Temperature Example
Suppose a solar panel has a temperature coefficient of -0.4% per °C.
The panel is rated at 25°C. Now imagine the solar cell reaches 50°C.
That is a 25°C increase.
At -0.4% per °C:
25 × 0.4% = 10%
Therefore, the panel could lose around 10% of its power compared with its output at the 25°C reference point, before considering other system losses.
This is only an example. Actual results depend on the panel’s temperature coefficient, sunlight level, wind, mounting method and other conditions.
What Is NOCT and Why Does It Matter?
Another important term is NOCT, which means Nominal Operating Cell Temperature.
NOCT gives a better idea of how a solar panel behaves in real outdoor conditions. The standard NOCT test uses 800 W/m² of sunlight, an ambient temperature of 20°C and wind speed of 1 m/s.
Under these conditions, the panel cell temperature can be much higher than the surrounding air.
For many crystalline silicon panels, typical NOCT values are around the mid-40°C range. This shows why looking only at outdoor air temperature can be misleading.
In addition, the way a panel is installed affects its temperature. A panel with good airflow behind it can release heat more easily. On the other hand, restricted airflow can allow heat to build up..
Does More Sunlight Mean More Solar Power?
Generally, yes, but there is a balance.
More sunlight usually gives a solar panel more energy to convert into electricity. However, strong sunlight also heats the panel. As the panel gets hotter, its power output can fall because of the temperature effect.
Therefore, a cool and sunny day can sometimes provide excellent solar performance.
For example, a bright spring day may produce strong results even when the air feels cool. Meanwhile, a very hot summer afternoon can have intense sunlight but lower panel efficiency because the cells are much hotter.
This is one reason solar system performance should be judged over the whole year rather than by one very hot day.
Does Cold Weather Improve Solar Panel Efficiency?
Yes. Cold temperatures can help solar panels perform efficiently.
However, cold weather alone does not guarantee high electricity production. The panels still need sunlight.
For instance, a cold winter day with clear skies can be very productive. In contrast, a cold day with heavy cloud cover may produce much less electricity.
Therefore, temperature and sunlight work together. A solar panel needs enough sunlight, while cooler cell temperatures can help it convert that sunlight more efficiently.
How Can Businesses Reduce Solar Panel Heat?
For commercial buildings, good system design can help control operating temperatures.
First, professional installers should consider airflow around the panels. Roof-mounted systems should have suitable spacing where the mounting design allows it.
Second, the roof type and mounting system should be considered carefully. A well-designed installation can help air move behind the modules and remove some heat.
Third, businesses should choose panels with suitable temperature coefficients. A lower negative temperature coefficient means the panel loses less power as its temperature rises.
Furthermore, the inverter and other electrical equipment should also be selected for the site conditions. Heat can affect several parts of a solar PV system, not only the panels.
Why Temperature Matters for Commercial Solar Systems
Temperature becomes even more important for large commercial solar installations.
A business may install hundreds or thousands of panels across a large roof. Even a small percentage loss can affect the amount of electricity generated across the whole system.
As a result, a commercial solar company should assess the building, roof, local climate, panel specifications and expected energy use before designing the system.
Professional solar modelling can also account for temperature and other environmental conditions. The U.S. Department of Energy notes that solar performance models use factors such as solar radiation, temperature and system losses to estimate electricity production.
Other Factors That Affect Solar Panel Efficiency
Temperature is important, but it is not the only factor.
Solar panel performance can also change because of:
- Sunlight levels: More useful sunlight usually means more electricity.
- Shading: Trees, buildings and nearby structures can reduce production.
- Panel direction: The position of the panels affects how much sunlight they receive.
- Panel angle: The roof pitch and mounting angle can affect solar exposure.
- Dust and dirt: Dirty panels can receive less usable sunlight.
- Wind: Wind can help remove heat from the panel surface.
- Ventilation: Good airflow can help keep modules cooler.
- Panel technology: Different solar cells have different temperature characteristics.
- Inverter efficiency: The inverter also affects the electricity delivered to the building.
- System design: Wiring, connections and other equipment can create additional losses.
Consequently, the best solar system is not simply the one with the highest panel efficiency rating. The complete installation matters.
What Is the Best Temperature for Solar Panels?
The short answer is around 25°C at the solar cell temperature, because this is the standard reference temperature used for panel ratings.
However, solar panels can still generate electricity at much higher temperatures. They do not suddenly stop working when the temperature rises above 25°C. Instead, their power output normally decreases as cell temperature increases.
Therefore, businesses should not avoid solar because their area has hot summers. A properly designed solar PV system can still generate substantial electricity in warm climates.
Final Thoughts
Solar panels like sunlight, but they do not like excessive heat. Around 25°C cell temperature is the standard reference point for peak rated performance. In real conditions, the solar cells can become much hotter than the outside air. As temperature rises, voltage normally falls, which reduces the panel’s power output.
For this reason, businesses should look beyond the panel’s headline efficiency rating. A suitable commercial solar company can assess the roof, sunlight, ventilation, panel temperature coefficient, inverter and expected energy demand.
Ultimately, good design helps a commercial solar system produce reliable electricity throughout the year. Cool, sunny conditions can be especially favourable, while proper airflow and suitable equipment can help manage the effects of high temperatures.
